Specifications
Posts
Ranging from 4″ Sq tube to 8″ Sg tube determined by wind load rating
Wall thicknesses start at 1/4″ and go to 1/2″
Red oxide primer – standard
* Galvanized – (optional)
Gates
Ranging from 2 1/2″ Sq tube to 4″ Sg tube determined by wind load rating
Wall thicknesses start at 1/8″ and go to 1/4″
Red oxide primer – standard
* Galvanized – (optional)
Inserts
2 x 2 x 1/4″ Aluminum Tee Frame
Filler Options:
1/2″ B Deck 20 GA Galvanized
1 x 6″ Aluminum planks – Tongue & grooved (Wood look)
1/2 x 2 Aluminum tube louvers
Hinge Pins
Bolts ranging from 3/4″ to 1 1/4″ determined by wind load rating
Gates glide on a bronze thrust washer
Latching Rods
1″ diameter to 1 1/2″ diameter determined by wind load rating
Rods latch in the open and closed position by dropping into sector hole on post plate
Leveling System
1) Retro – Fit System:
U Brackets placed under gates which use all thread rod to hold level gates to assist while welding gates to existing posts
2) New Construction:
Rectangular tubing is used to attach both gates together into one unit
Posts come with all thread leveling legs
Once all pieces are bolted together the leveling legs will support system and allow for proper adjustments before pouring concrete
